FN-500W
FUNELEC
| Parameters Table | |||
| product name | TY500 Battery charger | Brand | FUNELEC |
| model | TY500-4815 | Frequency | 47～60Hz |
| AC input voltage | 220VAC | Net weight | 2.5KG |
| 110VAC | |||
| DC output voltage | 12.6V | DC output current | 39A |
| Size | 215*130*50mm | Shell material | Steel plate |
| shell color | Yellow | Efficiency | ≥88% |
| Applicable battery type | 14S 12.6V lithium battery | ||
| （S = Tandem） | |||
| Charging mode | Three-stage intelligent charging mode: constant current ~ constant voltage ~ trickle (floating charge) | ||
| Make sure the battery is fully charged (float charging is when a lead acid charger is used) | |||
| Charging indicator | Red and green two-color indication, red light means charging | ||
| Green light indicates fully charged or standby | |||
| Working conditions | Working environment temperature: -20～+40℃; Relative humidity: 5～95%; | ||
| Maximum altitude: 12000 meters | |||
| Storage conditions | Storage environment temperature: -40～+70℃; Relative humidity: 0～95%; | ||
| Maximum altitude: 20000 meters | |||
| Multiple protection | Over current, over voltage, over temperature, short circuit, reverse polarity, | ||
| Trickle or anti-backfill | |||
| Product advantages | 1. Safety certification CE, RoHS, FCC directive compatible, intelligent IC control, CC, CV | ||
| Float /Cut-off rickle automatic conversion to meet the needs of different curves. | |||
| 2.Steel plate shell, sturdy, elegant, safe, stable and reliable. | |||
| 3. Affordable. | |||
| It has an integrated MCU and PWM for power control. | |||
| Package Contents | * 1x battery charger | ||
| * 1x AC power cord | |||
| * 1x User Manual (Product Instruction Manual) | |||
